Dow Controls Laboratory
Keysight InfiniiVision MSOX3024T
Basic Specifications
200 MHz; 5GSa/s; 4 analog & 16 digital channels; 1,000,000 wfms/s update rate; 4 Mpts memory; 20MHz waveform generator; 3-digit voltmeter
5.0 Metre Flume, TecQuipment FC80-5 (OCEN 336)
Basic Specifications
The FC80-5 Flow and Sediment Transport Channel is 5 meters in length and 80mm in width.
The flume has a built-in recirculating water supply connected to a digital flow meter for accurate measurements during experimentation.
The angle of the flume can be adjusted manually and an angleometer is used to display the current angle.
Multiple attachments are available to analyze different flow situations.
Keysight 34461A 6.5
Basic Specifications
35 ppm basic DCV accuracy; Max reading rate 1000 rdgs/s; Memory 10000 rdgs
Keysight E36311A
Basic Specifications
3 channels; Channel 1: 0-6V, 0-5A; Channel 2: 0-25V, 0-1A; Channel 3: -25-0V, 0-1A
Keysight EDU36311A Power Supply
Basic Specifications
3 channels; Channel 1: 0-6V, 0-5A; Channel 2: 0-30V, 0-1A; Channel 3: -30-0V, 0-1A
KEYSIGHT EDU34456A Digital Multimeter
KEYSIGHT DSOX1204G (200MHZ)
NI cDAQ-9174
NI 9237 Strain Gauge Data Acquisition Module
Basic Specifications
50 kS/s/channel, Bridge Analog Input, 4-Channel C Series Strain/Bridge Input Module
NI cDAQ-9210 Thermocouple Data Acquisition Module
Basic Specifications
4-Channel, 14 S/s Aggregate, ±80 mV C Series Temperature Input Module
NI cDAQ-9263 Analog Output Module
Basic Specifications
100 kS/s/ch Simultaneous, ±10 V, 4-Channel C Series Voltage Output Module
NI 9201 Analog Input Module
Basic Specifications
±10 V, 500 kS/s, 12-Bit, 8-Channel C Series Voltage Input Module
Q8-USB Data Acquisition Device
Quanser Volt PAQ Power Supply
Quanser Coupled Tank Experiment
Basic Specifications
The Coupled Tanks system is a process control experiment ideal for teaching and research of control topics related to liquid level control.
Quanser SRV02 Motor Lab
Basic Specifications
The Rotary Servo Base Unit is ideally suited to introduce basic control concepts and theories.
PCB Piezo Electric Accelerometer
Basic Specifications:
Sensitivity: (±5%)100 mV/g (10.19 mV/(m/s²));Measurement Range: ±50 g pk (±491 m/s² pk);Broadband Resolution: 0.0005 g rms (0.005 m/s² rms);Frequency Range: (±5%)1 to 4000 Hz
Shimpo Handheld Force Gauge
Dwyer Anemometer
Basic Specifications
Air Velocity Range: 79 to 4921 fpm, 0.4 to 25 m/s; Air Volume Range: 0 to 9999 CFM; Temperature Range: -4 to 140°F; Barometric Pressure Range: 10.3 to 32 in Hg; Air Velocity Accuracy: ±2% FS; Temperature Accuracy: ±1.8°F; Barometric Pressure Accuracy: ±0.1 in Hg; Vane Diameter: 1.18″ (30 mm)
Mettler Toledo Analytical Balance
Basic Specifications:
Maximum Capacity 120g; Readability .1mg, Minimum Weight 16mg, Temperature accuracy +/-2 ppm/°C, Resolution 0.1mg
Cole Parmer Hot Plate
Cole-Parmer Viscometer
Fluid Friction Apparatus (Academic Instruction Only)
Basic Specifications
Allow students to investigate the phenomena of laminar, transitional and turbulent flows in pipe systems
Hydraulic Water Bench (Academic Instruction Only)
Basic Specifications
Provides a controlled recirculating water supply and accurate flowmeter for hydraulic and fluid mechanics experiments.
Gas Adsorption (Academic Instruction Only)
Basic Specifications
The Armfield Fixed Bed Adsorption Column UOP15 apparatus has been designed to study the adsorption characteristics of activated carbon using a mixture of helium and carbon dioxide.
The carbon dioxide is adsorbed to determine the capacity of the fixed bed in addition to the study of adsorption exotherms.
The carbon dioxide is then desorbed to study the associated endotherm.
Emerson Performance Learning Platform (Academic Instruction Only)
Basic Specifications
The Performance Learning Platform is fully instrumented with the latest Emerson technology.
The Platform pumps water from Tank 1 to Tank 2 and measures flow, tank level, pressure and temperature through Rosemount, Micro Motion and Fisher devices controlled by the newest DeltaV PK controller.
Gas Compressibility
Corrosion Potentiostat with electrochemical cell, Interface 1010E
Basic Specifications
The interface 1010E is used extensively for electrochemical corrosion, battery testing, fuel cell testing and physical electrochemistry. It features max applied current, ±1A, max applied potential ±12V and EIS 10μHz to 2MHz.
Schneider Cyber Physical Systems Laboratory
Keysight InfiniiVision MSOX3024T
Basic Specifications
200 MHz; 5GSa/s; 4 analog & 16 digital channels; 1,000,000 wfms/s update rate; 4 Mpts memory; 20MHz waveform generator; 3-digit voltmeter
Keysight 34461A 6.5
Basic Specifications
Accuracy 35 ppm basic DCV ; Max reading rate 1000 rdgs/s; Memory 10000 rdgs;
Keysight E36311A
Basic Specifications
3 channels; Channel 1: 0-6V, 0-5A; Channel 2: 0-25V, 0-1A; Channel 3: -25-0V, 0-1A
Keysight EDU33212A Waveform Gen
Basic Specifications
Frequency Range -1 µHz to 20 MHz, 1 µHz resolution; overshoot <3%; Waveform Length 8Sa-8MSa per channel; Sample Rate 1 µSa/s to 250 MSa/s, 1 µSa/s resolution; Voltage Resolution 16 bits
NI ELVIS III
Basic Specifications
Includes breadboard, DMM, DC power supply, oscilloscope, function generator, digital I/O. See spec sheet for more.
Weller WE1010 Soldering Station
Basic Specifications
200°F–850°F; 100°C–450°C; Accuracy +/- 17°F,9°C; Stability +/- 4°F, 2°
Shell Transport Phenomena Laboratory
Water Bath
Basic Specifications
200°F–850°F; 100°C–450°C; Accuracy +/- 17°F,9°C; Stability +/- 4°F, 2°
Ni cDAQ-9171 Data Acquisition System
Basic Specifications
200°F–850°F; 100°C–450°C; Accuracy +/- 17°F,9°C; Stability +/- 4°F, 2°
NI cdaq-9213 Thermocouple module
Basic Specifications
200°F–850°F; 100°C–450°C; Accuracy +/- 17°F,9°C; Stability +/- 4°F, 2°
Techquipment te78 condensation and boiling apparatus (Academic Instruction Only)
Basic Specifications
200°F–850°F; 100°C–450°C; Accuracy +/- 17°F,9°C; Stability +/- 4°F, 2°
tecquipment td1005 free and forced convection (Academic Instruction Only)
Basic Specifications
200°F–850°F; 100°C–450°C; Accuracy +/- 17°F,9°C; Stability +/- 4°F, 2°
tecquipment td1002 heat transfer base experimnet
Basic Specifications
200°F–850°F; 100°C–450°C; Accuracy +/- 17°F,9°C; Stability +/- 4°F, 2°
TECQUIPMENT TD1002a linear heat conduction (Academic Instruction Only)
Basic Specifications
200°F–850°F; 100°C–450°C; Accuracy +/- 17°F,9°C; Stability +/- 4°F, 2°
TECQUIPMENT TD1002b radial heat conduction (Academic Instruction Only)
Basic Specifications
200°F–850°F; 100°C–450°C; Accuracy +/- 17°F,9°C; Stability +/- 4°F, 2°
TECQUIPMENT TD1002c extended surface heat transfer (Academic Instruction Only)
Website
Basic Specifications
200°F–850°F; 100°C–450°C; Accuracy +/- 17°F,9°C; Stability +/- 4°F, 2°
tecquipment td360 Heat exchanger base unnit
Basic Specifications
200°F–850°F; 100°C–450°C; Accuracy +/- 17°F,9°C; Stability +/- 4°F, 2°
TECQUIPMENT TD360a concentric tube heat exchanger (Academic Instruction Only)
Basic Specifications
200°F–850°F; 100°C–450°C; Accuracy +/- 17°F,9°C; Stability +/- 4°F, 2°
TECQUIPMENT TD360b plate heat exchanger
Basic Specifications
200°F–850°F; 100°C–450°C; Accuracy +/- 17°F,9°C; Stability +/- 4°F, 2°
TECQUIPMENT TD360c shell and tube heat exchanger (Academic Instruction Only)
Basic Specifications
200°F–850°F; 100°C–450°C; Accuracy +/- 17°F,9°C; Stability +/- 4°F, 2°
TECQUIPMENT vdas mkII data acquisition (Academic Instruction Only)
Basic Specifications
200°F–850°F; 100°C–450°C; Accuracy +/- 17°F,9°C; Stability +/- 4°F, 2°
northslope water chiller large
Basic Specifications
200°F–850°F; 100°C–450°C; Accuracy +/- 17°F,9°C; Stability +/- 4°F, 2°
northslope water chiller small
Basic Specifications
200°F–850°F; 100°C–450°C; Accuracy +/- 17°F,9°C; Stability +/- 4°F, 2°
thermal radiation sensor
Basic Specifications
200°F–850°F; 100°C–450°C; Accuracy +/- 17°F,9°C; Stability +/- 4°F, 2°
stefan-boltzman lamp
Basic Specifications
200°F–850°F; 100°C–450°C; Accuracy +/- 17°F,9°C; Stability +/- 4°F, 2°
infrared thermometer
FLUKE 568 IR Thermometer
